S/SS/SXS/SMS PP Spunbond Nonwoven making production line

Basic Info

Model No.: YF-S/SS/SSS/SMS

Product Width: 1.6m-4.2m

Machine Model: S/SS/SSS/SMS/SSMS/SSMMS

Additional Info

Packaging: Nude packing , wooden case is optional. case packing:Carding machine, lapper and electric boxes wooden case packaged. Other machines nude packaging. Any damage in transport of machines is not duty of the

Brand: AOLONG

Transportation: Ocean

Place of Origin: Zhejiang, China (Mainland)

Port: Ningbo,Shanghai

Product Description

Product Description

S/SS/SXS/SMS PP Spunbond nonwoven making production line

spunbond nonwoven making machine

nonwoven making machine

spunbond making machine

1.1 Raw material: Polypropylene chips (Melt index: 30-40g/10min, with variation not more than 1% for each batch; Melt point: 168℃; Ash content: ≤0.15-0.25%

1.2 Width of finished fabric: 1200mm

1.3 Single filament titer: 1.5-2.5 denier

1.4 Annual output: 1100 tons/year (say 7,200hours per year, over 20gsm)

1.5 Web weight: 10-250 g/m2

1.6 GSM Variation: CV value less than 5%

1.7 Extruder size: φ105 L/D=30:1

1.8 Process speed: 10~150m/min

1.9 Installed power: about 462kw

2.0 Factory Effective Size: 28000mm*16000mm*7500mm

2.1 No. of spin beams: 1 set

MEDICAL AND HEALTH:Operation suit , operation tablecloth, patient suit, exposure suit, respirator, packing bags,etc.

LABOR SAFETY GOODS:Protect clothing, cover for car and motor , dust cover , raincoat, work clothes for spraying the paint ,etc .

TRAVELLING GOODS:Beach umbrella , beach suit, recovery bag ,etc.

CLEANING GOODS : Baby's diaper, pad for incontinent adults , sanitary towel, filtering material.etc.

size:1600mm 2000mm 2400mm 3200mm 4000mm

color:free

fabrice GSM:15---250GSM

filament :φ1.5--1.7

annual output:3500--6500T/Y

Detailed Images

To feed chips from the ground to the dosing and mixing system on the third floor.

Main material and auxiliary materials can be prepared as per a certain ratio.

Dosing and mixing device, consisting of a main material tank, two auxiliary tanks, a mixing tank, a suction device

Extruder is used to melt and extruder PP Chips, master batches and some additives such as antioxidant, anti-pilling agent and flame retardant agent. And, the extruder machine consists of chip inlet, automatic temperature control, cooling device and alarming device.

Main drive employs A.C. frequency control. The temperature control for each zone adopts closed-loop system with WEST temperature meter, solid relay and pt100 platinum resistance.

Packing & Delivery

Nude packing , wooden case is optional.

case packing:Carding machine, lapper and electric boxes wooden case packaged. Other machines nude packaging.
